| CPU |
Intel High Performance CPU |
| Memory |
4 GB Flash (DOM)
2 GB DDR 4 memory |
| Storage Capacity per HDD |
Up to 18TB |
| HDD Tray |
8 |
| Maximum Capacity |
Up to 144TB |
| LAN Port |
2 x 2.5 Gigabit RJ-45 Ethernet port |
| LED Indicators |
HDD1, HDD2, HDD3, HDD4, HDD5, HDD6, HDD7, HDD8, LAN1, LAN2 |
| USB Connector |
Front: 2 x USB 3.2 Gen 1x1
Back: 4 x USB 3.2 Gen 1x1
|
| Buttons |
Power, USB backup(reserve) |
| Video Output Connector |
HDMI 2.0a x 2 (for local display) |
| Alarm Buzzer |
System warning |
| Form Factor |
Rack mount |
| Operation Environment |
Temperature 0~40˚C
Humidity 5~95% R.H. |
| Power Supply |
Input: 100-240V AC, 50/ 60Hz
Output: 300W |
| Power Consumption |
Operation: 76~84 W
(with 8 x 500GB HDD installed in RAID 5 building process) |
| Fan |
3 x cooling fan (8cm) |
| H/ W Dimensions |
88.8 (H) x 430 (W) x 554 (D) mm
3.49 (H) x 16.9 (W) x 21.8 (D) inch |
| Color Box Dimensions |
213 (H) x 742 (W) x 582 (D) mm
8.4 (H) x 29.2 (W) x 22.9 (D) inch |
| Carton Dimensions |
245 (H) x 764 (W) x 602 (D) mm
9.6 (H) x 30 (W) x 23.7 (D) inch |
| Color Box Shipping Weight |
Net Weight (kg/PC): 11.98
Gross Weight (kg/PC): 13.98
Gross Weight (kg/CTN): 13.98 |
